TX7302 Addressable Sounder Base
- EN54-3 Compliance
- 8 high-light LED Loop powered sounder strobe detectorbase
- Can be activated by the attached detector
- Built-in MCU processor and digital addressing
- 17 tones Programmable sound output
- Programmable Evacuate or Pre-alarm/Evacuate signal
- Programmable One or Two address mode
- Onsite Adjustable Parameters
- Mounting base using TX7980 (excluded)
Description
Technical Specifications
| Approvals | LPCB / CE-CPR |
| Input Voltage | Loop Power: 24VDC [16V to 28V] |
| Current Consumption | Standby≤0.8mA, Alarm: ≤5mA [Loop powered] |
| Protocol / Addressing | T&A, Value range from 1 to 254 |
| Addressing Mode | Single Mode: Alarm tone Dual Mode 1: 1st Alarm / 2nd Warning Dual Mode 2: 1st Warning / 2nd Alarm |
| Material / Colour | ABS / White Glossy finishing |
| Diameter / Height | D: 140 mm / H: 59.1 mm (with cover) |
| Weight | 198g (with cover) / 180g (without cover) |
| Class | Type A, Indoors |
| Ingress Protection Rating | IP30 |
| Operating Temperature | -10°C to +55°C |
| Humidity | 0 to 95% RH, Non-condensing |
