Simplex 4906-9131 Weatherproof Multi Candela Horn Strobe

QAR240.00

The Simplex 4906-9131 is a TrueAlert® weatherproof multi-candela horn/strobe designed for wall-mounted audible and visible fire alarm notification in indoor or outdoor applications. This non-addressable 24 VDC appliance features a NEMA 3R rated enclosure suitable for extended temperature and humidity environments. The strobe intensity is field-selectable, and the unit supports SmartSync two-wire operation, allowing independent horn and strobe control on the same NAC. The polarized input connects to compatible reverse polarity supervised notification appliance circuits. The 4906-9131 is UL and ULC listed and FM approved for regulated 24 VDC operation.

Description

Weight 0.4 lbs
Dimensions 4.34 × 6.13 × 5.53 in
Manufacturer Simplex Manufacturing Company
Brand Simplex
Condition New
Unit of Measurement EA (Each)
Production Status Active
Mounting Wall
Color Red
Series TrueAlert Weatherproof Multi-Candela
Location Indoor, Outdoor
Operating Voltage 24V DC
Voltage Range 16 – 33 VDC
Candela 15 cd, 60 cd, 75 cd
Flash Rate 1 Hz
Sound Level (DBA) 83 dBA @ 10 ft
Operating Temperature Range -31°F to 150°F (-35°C to 66°C)
Humidity Rating up to 98%, at 104°F (40°C)
Wiring Terminal Block
Listings & Approvals CSFM, FM, UL, ULC
