Previdia Max Modular Control Panel
Previdia Max is the ideal analogue-addressable control panel for large-scale fire detection systems. Its modular design allows configuration from 1 to 4 cabinets, managing up to 32 IFM modules and supporting complex installations such as airports, hospitals, shopping malls, and industrial facilities. Thanks to HOT SWAP technology, modules can be replaced without shutting down the panel. The 7″ color touchscreen display and interactive graphical maps enable intuitive, fast, and accurate system management, while the IP video verification feature enhances responsiveness in case of an alarm.
Description
•7’’ touch screen, 65000 colours
• Emergency backup CPU
• 2 loops expandable to 16 (using IFM2L module)
• Certified LPCB CPR EN54 pt2 for the management of 512 fire detection points
• Certified LPCB CPR EN54 pt4
• Certified EN54 pt21 over PSTN, GSM and TCP-IP channels
• Certified EN12094-1 (fire extinguishing systems) up to 24 channels
• 1 Ethernet port for configuration via PC and TCP/IP connection for programming
• 1 RS232 port for configuration via PC and firmware upgrade
• 1 RS485 port for FPMCPU repeater (max. 14)
• 1 mini USB Port for configuration via PC
• 1 MODBUS RTU port
• 1 microSD card holder
• 2 CAN BUS ports
• 1 voltage-free relay 5A 30Vdc
• 1 programmable supervised alarm output 1.5A @27.V
• 1 output for external power 1.5A @27.6V
• Multi-processor hardware architecture
• Dedicated microprocessor for each module
• Scandinavian key for level 2 access
• Signalling LED and multiple-alarm scroll button
• 6 status LEDs
• 6 LED and function buttons
• Speaker
• Power supply voltage: 230 / 115 V~ (+10% -15%) 50/60 Hz
• Maximum current draw from mains: 1.1A @230V, 2A@115V
• Maximum available current: 5.2A
• Battery charger: 1.2A
• 1 CAN DRIVE bar for the connection of internal IFM modules (max 8)
• Battery housing for 2 batteries max. 24Ah@12V
• Dimensions: 433 x 563 x 187 mm (PRCAB)
• 19’’ rack mount (via PRCABRK)
• Possibility to connect up to 4 cabinets together
• Weight: 10Kg (PRACAB)
• Protection grade: IP 30
